Rigol DHO914S

To Next Page

To Previous Page

TIP

When the waveform view window is closed, the "Waveform View" item appears on the

Diagram menu. You can use the item to open the waveform view window.

Add Result Table Window

Click or tap "Measure", "All Measure", or "Decode" in

Result Table, and then click

or tap

Add. The corresponding measurement results will be displayed on the screen.

Multi-pane Windowing

219
