RIGOL Chapter 2 Front Panel Operations
2-100 DL3000 User’s Guide
(3) ManualIP (manual configuration)
In this mode, you can self-define the network parameters (such as the IP
address) of the instrument. Press ManualIP to enable or disable the
manual IP configuration mode. By default, it is "OFF".
If you enable this mode, "IP Address", "SubMask", "Gateway", and "DNS" at the
right section of the interface can be editable.
If you set "ManualIP" to be "ON", then "DHCP" and "AutoIP" will both be
automatically set to "OFF"; if you set "ManualIP" to be "OFF", then "DHCP" and
"AutoIP" will both be automatically be set to "ON".
Set IP Address
In the manual IP mode, you need to acquire an available IP address from
the administrator, and then configure the IP address manually. The format
of the IP address is "nnn.nnn.nnn.nnn". The range for the first segment
(nnn) of the address is from 1 to 223 (except 127); and the range for the
other three segments is from 0 to 255.
In the manual IP mode, press the Up/Down arrow key to switch the
parameter focus to "IP Address", and then press the Left/Right arrow key to
move the cursor. Use the numeric keys or the knob to input the IP address.
The setting is saved to the non-volatile memory. If "Power-on" is set to
"Last", and the next you power on the instrument, set both "DHCP" and
"AutoIP" to "OFF", in this case, the instrument will automatically load the
set IP address.
Set the subnet mask
In the manual IP mode, you need to acquire an available subnet mask from
the administrator, and then configure the subnet mask manually. The
format of the subnet mask is "nnn.nnn.nnn.nnn". The range for the first
segment (nnn) is from 0 to 255.
In the manual IP mode, press the Up/Down arrow key to switch the
parameter focus to "SubMask", and then press the Left/Right arrow key to
move the cursor. Use the numeric keys or the knob to input the subnet
mask.
The setting is saved to the non-volatile memory. If "Power-on" is set to
"Last", and the next you power on the instrument, set both "DHCP" and
"AutoIP" to "OFF", in this case, the instrument will automatically load the
set subnet mask.
