Technical Specifications
Specifications of DM306x
DC Characteristics
Accuracy Specifications (% of reading + % of range)
[1]
Function
Range
[3]
Test Current
or Burden
Voltage
24 Hour
[2]
Tcal± 1℃
90 Day
Tcal± 5℃
1 Year
Tcal± 5℃
Temperature
Coefficient
0 ℃ to
(Tcal–5 ℃)
(Tcal + 5 ℃) to
55 ℃
DC
Voltage
200.0000mV
0.0030+0.00
30
0.0065+0.00
65
0.0085+0.00
70
0.0005+0.0007
2.000000V
0.0020+0.00
06
0.0060+0.00
07
0.0078+0.00
07
0.0005+0.0001
20.00000V
0.0020+0.00
04
0.0065+0.00
05
0.0085+0.00
05
0.0005+0.0001
200.0000V
0.0020+0.00
06
0.0082+0.00
11
0.0100+0.00
12
0.0007+0.0002
1000.000V
[5]
0.0025+0.00
06
0.0095+0.00
10
0.0110+0.00
10
0.0010+0.0001
DC
Current
2.000000mA
<0.03V
0.010+0.014
0.060+0.035
0.076+0.050
0.0027+0.0070
20.00000mA
<0.3V
0.010+0.002
0.058+0.006
0.075+0.006
0.0027+0.0007
200.0000mA
<0.3V
0.020+0.002
0.065+0.005
0.081+0.005
0.0027+0.0008
1.000000A
<0.3V
0.020+0.016
0.065+0.030
0.073+0.030
0.0027+0.0062
10.00000A
[7]
<0.6V
0.300+0.020
0.330+0.020
0.330+0.020
0.0030+0.0025
Resistance
[4
]
200.0000Ω
1mA
0.0106+0.00
97
0.018+0.011
0.020+0.011
0.0008+0.0007
2.000000kΩ
1mA
0.0022+0.00
11
0.010+0.002
0.015+0.002
0.0008+0.0001
20.00000kΩ
100uA
0.0020+0.00
06
0.010+0.001
0.015+0.001
0.0008+0.0001
200.0000kΩ
10uA
0.0020+0.00
05
0.010+0.001
0.015+0.001
0.0008+0.0001
1.000000MΩ
2uA
0.0020+0.00
10
0.010+0.001
0.015+0.001
0.0008+0.0002
10.00000MΩ
200nA
0.0112+0.00
5
0.0550+0.00
6
0.056+0.006
0.0060+0.0004
100.0000MΩ
200nA||10M
Ω
0.300+0.010
0.800+0.011
0.800+0.015
0.1500+0.0002
Diode Test
2.4000V
[6]
1mA
0.005+0.050
0.008+0.050
0.010+0.050
0.0010+0.0020
Continuity
2000Ω
1mA
0.005+0.050
0.008+0.050
0.010+0.050
0.0010+0.0020
Notes：
[1] Specifications are for 60 minute warm–up and set reading resolution as 6½ .
[2] Relative to calibration standards.
