Rigol DM3000 Series Service Guide

RIGOL
Service Guide for DM3000 Series
5-1
Chapter 5 Disassembly & Assembly
The chapter mainly covers the following topics:
 The Disassembly and Assembly Notice
 The 3D View of DM3000
 To Disassemble and AssembleHandle, Rear Panel and Metallic Shell
 To Disassemble and Assemble Fuse Socket, BNC Module and GPIB PCB
 To Disassemble and Assemble Filter Board and Transformer
 To Disassemble and Assemble Front Panel and LCD
 To Disassemble and Assemble Multiplexer Board, Motherboard and Key Board PCB

Rigol DM3000 Series Specifications

General

Brand	Rigol
Model	DM3000 Series
Category	Multimeter
Language	English
