Rigol DM3000 Series Service Guide

RIGOL
Service Guide for DM3000 Series
1-15
AC Characteristics
Accuracy Specifications (% of reading + % of range)
[1]
Function
Range
[2]
Frequency Range
1 Year
23℃±5℃
Temperature
Coefficient
0 ℃ to 18 ℃
28 ℃ to 55 ℃
True RMS AC
Voltage
[3]
200.000mV
10Hz-45Hz
1.0 + 0.1
0.02+0.02
45Hz-20kHz
0.2 + 0.1
0.02+0.02
20kHz-50kHz
2.0 + 0.2
0.02+0.02
50kHz-100kHz
4.0 + 0.2
0.02+0.02
2V to
750.00V
10Hz-45Hz
1.0 + 0.1
0.02+0.02
45Hz-20kHz
0.2 + 0.1
0.02+0.02
20kHz-50kHz
1.0 + 0.1
0.02+0.02
50kHz-100kHz
2.0 + 0.2
0.02+0.02
True RMS AC
Current
[4, 6]
20.0000mA
10Hz-45Hz
1.5+0.1
0.02+0.02
45Hz-2kHz
0.5+0.1
0.02+0.02
2kHz-10kHz
2.0+0.2
0.02+0.02
200.000mA
10Hz-45Hz
1.5+0.1
0.02+0.02
45Hz-2kHz
0.5+0.1
0.02+0.02
2kHz-10kHz
2.0+0.2
0.02+0.02
1.00000A
10Hz-45Hz
1.5+0.5
0.02+0.05
45Hz-2kHz
0.5+0.5
0.02+0.05
2kHz-10kHz
2.0+0.5
0.02+0.05
10.0000A[6]
10Hz-45Hz
1.5+0.1
0.02+0.02
45Hz-2kHz
0.5+0.1
0.02+0.02
2kHz-5kHz
2.0+0.2
0.02+0.02
Notes：
[1] Specifications are for 60 minute warm–up and set reading resolution as 5½ and calibration
temperature between 18 ℃ and 28 ℃.
[2] 20% over range on all ranges, except DCV 1000V, ACV 750V, DCI and ACI 10A range.
[3] Specifications are for sine wave input >5% of range. For inputs from 1% to 5% of range and
<50 kHz, add 0.1% of range additional error. For 50 kHz to 100 kHz, add 0.13% of range.
750Vac range limited to 100 kHz or 8x10
7
Volt-Hz.
[4] Specifications are for sine wave input >5% of range. Add 0.1% of the range for the sine wave
input is 1%~5% of the range.
[5] For current terminal, > 7A DC or ACRMS for 30 seconds ON and 30 seconds OFF.
