RIGOL
Service Guide for DM3000 Series
Rear panel multiplexer function (only for the model with multiplexer module)
Including the model with multiplexer card, the voltage limit of LO relative to safe ground
falls to 200Vpeak (Max).
Channel: 12 voltage, 4 current, additional protections.
Measurement Type：2-Wire resistance; Capacitance; DC Voltage; DC Current; AC Voltage; AC
Current; period; Diode and Frequency.
Work Characteristics：The precision of performance and front panel measurement is the same.
The switch time of multiplexer card is 50ms; the switch time of auto measurement is 600ms (4½ ).
Input Characteristic: different input voltage is 150Vpeak(Max); the isolated voltage between the
channels is 150Vpeak(Max)，the current end is input 1Apeak(Max), channel isolation > 60dB
(@10KHz)，the voltage of all the ends relative to safe ground is 150Vpeak(Max).
Input Protection: 2A restore the fuse in current channel, 250V limit voltage.
500mA melt the fuse in voltage channel with multiplexer card.
Real-time Clock
Precision: 1min/month (Environment Temperature >0℃)
Clock battery Life: 2 years
Sensor Measurement
Voltage, current, resistance and frequency random sensor
Math Functions
Null, Min/Max/Average, dBm, dB, Limit Test (with TTL output)
Other Functions
Reading Hold, Ratio Measurement
High-speed Sampling
50kSa/s (In Datalog function)
Reading Resolution
480,000 Count, >5¾ digits
USB I/O Interface
USB Host, USB Device interface. It can support U-disk and USB printer.
