Table 3-5 DC Gain Error of the Standard Equipment (DM305X)
Test Signal
Function
Quick Test
Point
Range
Error (1 year)
2mA
DC Current
2.000000mA
± 2.4μA
20mA
Q
20.00000mA
± 11.6μA
200mA
200.0000 mA
± 118μA
1A
1.000000A
± 1.7mA
10A
[1]
10.00000A
± 20.7mA
400mV
DC Voltage
400.0000mV
± 132μV
4V
Q
4.000000V
± 1.24mV
40V
Q
40.00000V
± 12.4mV
400V
400.0000V
± 144mV
1000V
[2]
1000.000V
±350mV
400.0000Ω
2-Wire
Ohms/
4-Wire
Ohms
[3]
400.0000Ω
± 240mΩ
4.000000kΩ
4.000000kΩ
± 840 mΩ
40.00000kΩ
Q
40.00000kΩ
± 8.4Ω
400.000 kΩ
Q
400.0000kΩ
± 148Ω
4.000000MΩ
4.000000MΩ
± 2.8kΩ
100.00000MΩ
100.00000MΩ
± 2.005MΩ
Notes:
[1] Continuous current more than DC 7A or AC RMS 7A should be 30 seconds ON and 30 seconds
OFF;
[2] Each additional volt over ± 500 VDC adds 0.02 mV of error;
[3] Errors in above table are corresponding to 2-wire resistance function in math Null. Without Math
Null, the error is ± 0.2 Ω additional errors in 2–wire resistance function;
[4] The reading resolution of multimeter is 5½ ;
[5] Q: Optional quick test point.
