Chapter 1 Specifications RIGOL
Service Guide for DM3068
1-1
Chapter 1 Specifications
1. 1 DC Characteristics
Accuracy Specifications: ±(% of reading + % of range)
[1]
Function Range
[2]
Test Current or
Burden Voltage
24 Hour
[3]
T
CAL
℃
±1
℃
90 Day
T
CAL
℃
±5
℃
1 Year
T
CAL
℃
±5
℃
Temperature
Coefficient
0
℃
to (T
CAL
℃
-5
℃
)
(T
CAL
℃
+5
℃
) to 50
℃
DC Voltage
200.0000mV
0.0020+ 0.0020
0.0030 + 0.0025
0.0040 + 0.0025
0.0005 + 0.0005
2.000000V
0.0015 + 0.0005
0.0020 + 0.0006
0.0035 + 0.0006
0.0005 + 0.0001
20.00000V
0.0020 + 0.0004
0.0030 + 0.0005
0.0040 + 0.0005
0.0005 + 0.0001
200.0000V
0.0020 + 0.0006
0.0040 + 0.0006
0.0050 + 0.0006
0.0005 + 0.0001
1000.000V
[4]
0.0020 + 0.0006
0.0040 + 0.0010
0.0055 + 0.0010
0.0005 + 0.0001
DC Current
200.0000uA
<0.03V
0.010 + 0.012
0.040 + 0.015
0.050 + 0.015
0.0020 + 0.0030
2.000000mA
<0.25V
0.007 + 0.003
0.030 + 0.003
0.050 + 0.003
0.0020 + 0.0005
20.00000mA <0.07V 0.007 + 0.012 0.030 + 0.015 0.050 + 0.015 0.0020 + 0.0020
200.0000mA
<0.7V
0.010 + 0.002
0.030 + 0.003
0.050 + 0.003
0.0020 + 0.0005
2.000000A
<0.12V
0.050 + 0.020
0.080 + 0.020
0.100 + 0.020
0.0050 + 0.0010
10.00000A
[5]
<0.6V
0.100 + 0.010
0.120 + 0.010
0.150 + 0.010
0.0050 + 0.0020
Resistance
[6]
200.0000Ω
1mA
0.0030 + 0.0030
0.008 + 0.004
0.010 + 0.004
0.0006 + 0.0005
2.000000kΩ
1mA
0.0020 + 0.0005
0.008 + 0.001
0.010 + 0.001
0.0006 + 0.0001
20.00000kΩ
100uA
0.0020 + 0.0005
0.008 + 0.001
0.010 + 0.001
0.0006 + 0.0001
200.0000kΩ
10uA
0.0020 + 0.0005
0.008 + 0.001
0.010 + 0.001
0.0006 + 0.0001
1.000000MΩ
2uA
0.002 + 0.001
0.010 + 0.001
0.012 + 0.001
0.0010 + 0.0002
10.00000MΩ
200nA
0.015 + 0.001
0.030 + 0.001
0.040 + 0.001
0.0030 + 0.0004
100.0000MΩ
200nA || 10MΩ
0.300 + 0.010
0.800 + 0.010
0.800 + 0.010
0.1500 + 0.0002
Diode Test
2.0000V
[7]
1mA
0.002 + 0.010
0.008 + 0.020
0.010 + 0.020
0.0010 + 0.0020
