Rigol DP822A User Manual

Chapter 5 Specifications RIGOL
DP800 User’s Guide 5-1
Chapter 5 Specifications
All the specifications are guaranteed when the instrument has been working for
more than 30 minutes under the specified operation temperature.
Note: Unless otherwise noted, the specifications are applicable to all the channels of
the specified model.
DC Output (0
℃
to 40
℃
)
Channel (Range) Voltage/Current OVP/OCP
DP832
CH1
CH2
CH3
0 to 30V/0 to 3A
0 to 30V/0 to 3A
0 to 5V/0 to 3A
10mV to 33V/1mA to 3.3A
10mV to 33V/1mA to 3.3A
10mV to 5.5V/1mA to 3.3A
DP831
CH1
CH2
CH3
0 to 8V/0 to 5A
0 to 30V/0 to 2A
0 to -30V/0 to 2A
10mV to 8.8V/1mA to 5.5A
10mV to 33V/1mA to 2.2A
-10mV to -33V/1mA to 2.2A
DP821
CH1
CH2
0 to 60V/0 to 1A
0 to 8V/0 to 10A
10mV to 66V/10mA to 1.1A
10mV to 8.8V/10mA to 11A
DP811
Range1
Range2
0 to 20V/0 to 10A
0 to 40V/0 to 5A
10mV to 22V/10mA to 11A
10mV to 44V/10mA to 5.5A
Load Regulation Rate ±(Output Percentage+Offset)
Voltage <0.01%+2mV
Current <0.01%+250μA
Linear Regulation Rate ±(Output Percentage+Offset)
Voltage <0.01%+2mV
Current <0.01%+250μA
Ripples and Noise (20Hz to 20MHz)
Normal Mode Voltage
DP831/DP832/DP821: <350μVrms/2mVpp
DP811: <350μVrms/3mVpp
Normal Mode Current <2mArms
Annual Accuracy
[1]
(25
℃
±5
℃
)±(Output Percentage+Offset)
Channel
Programming Readback
Voltage Current Voltage Current
DP832
CH1
CH2
CH3
0.05%+20mV
0.05%+20mV
0.1%+5mV
0.2%+5mA
0.2%+5mA
0.2%+5mA
0.05%+10mV
0.05%+10mV
0.1%+5mV
0.15%+5mA
0.15%+5mA
0.15%+5mA
DP831
CH1
CH2
CH3
0.1%+5mV
0.05%+20mV
0.05%+20mV
0.2%+10mA
0.2%+5mA
0.2%+5mA
0.1%+5mV
0.05%+10mV
0.05%+10mV
0.2%+10mA
0.1%+5mA
0.1%+5mA

Rigol DP822A Specifications

General

Brand	Rigol
Model	DP822A
Category	Power Supply
Language	English
