User‟s Guide for DS1000 Series
Check whether the Trigger Mode is set to “Normal” or “Single” and see whether the
trigger level is out of the signal range. If yes, set the trigger level in proper range by
turning the knob or pressing the 50% button. Or set the Trigger Mode as
“AUTO”. Moreover, push AUTO button to display the waveform on screen.
6. After the Acquisition is set to “Averages” or Display Persistence is set ON,
the waveform refreshes slowly.
It is normal in these settings.
7. The signal is displayed as ladder like waveform.
(1) The time base maybe is too slow. Turn the horizontal knob to
increase horizontal resolution to improve the display.
Maybe the display Type is set to “Vectors” set it to “Dots” mode to improve the
display.
