RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
2. The horizontal knob moves displayed signal horizontally on
waveform window
Horizontal offset back to 0 shortcut key
Press the knob to set the horizontal offset to 0 as a shortcut
key, this is especially helpful when the trigger point is far out of the screen and
want it to get back to the screen center immediately.
3. Press the MENU key to display the TIME menu.
To enter or exit the Delayed Scan mode, set the display to Y-T, X-Y or ROLL mode, and
turn the horizontal knob to adjust trigger offset.
Horizontal position control
Trig-Offset: In this setting, the trigger position will be changed horizontally
when you turn the knob.
To Next Page
