Rigol DS1000 Series

RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
5-2
Horizontal
Sample Rate Range
1Sa/s-400MSa/s (Real-Time), 25GSa/s (Equivalent)
Waveform interpolation
Sin(x)/x
Record Length
Up to 1M samples for single channel, at 400MSa/s
512K samples for each channel
512K samples **
Scan speed Range
(Sec/div)
2ns/div-50s/div, DS1102XX, DS1062XX
10ns/div-50s/div, DS1042XX
20ns/div-50s/div, DS1022XX
1-2-5 Sequence
Sample Rate and
Delay Time Accuracy
± 100ppm (over any 1ms time interval)
Delta Time
Measurement Accuracy
(Full Bandwidth)
Single-shot: ± (1 sample interval + 100ppm × reading
+ 0.6 ns)
>16 averages: ± (1sample interval + 100ppm × reading
+ 0.4 ns)
