User‟s Guide for DS1000 Series
Vertical offset back to 0 shortcut key
Turn the knob to change the vertical display position of
channel and press the knob to set the vertical display position
back to 0 as a shortcut key, this is especially helpful when the trace position is
far out of the screen and want it to get back to the screen center immediately.
2. Change the vertical setup and notice that each change affects the status
bar differently.
Change the vertical sensitivity with the knob and notice the change in
the status bar.
Press CH1 to turn on Channel 1.
A soft button menu appears on the display (or remains on if it was already turned
on).
Toggle the soft buttons and notice the changes in the status bar. Channel 1 and 2
have a vernier soft button that allows the knob to change the vertical
step size in smaller increments. To press Volts/Div soft button to change the step
size into Fine or Coarse status.
Press OFF button to turn off the channel.
To Next Page
