RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
Using Vertical and
You can use the vertical controls to display waveforms, adjust vertical and
, and set input parameters.
1. Using vertical knob.
The vertical control changes the position of signal waveforms in all
channels (including MATH and REF). The resolution changes according to the
vertical level set. Pressing this knob will clear the channel offset to zero.
2. Using vertical knob.
The vertical can change the vertical sensitivity of waveforms in all
channels (including MATH and REF, excluding LA). If the Volts/Div is set to
“Coarse”, the waveform scales in a 1-2-5 step sequence from 2 mV to 5 V. If the
Volts/Div is set to “Fine”, it scales to small steps between the coarse settings.
3. Channels can be adjusted by the vertical and only when
they are selected.
4. During the vertical position, a position message is displayed on the left bottom of
the screen, in the same color as the corresponding channel. The unit is V (Volts).
