RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
Figure 2-57 Table 2-33 The Alternative menu (Trigger Type: Video Page 1/2)
Set trigger mode for Channel 1
Set trigger mode for Channel 2
Video Trigger for the channel
Normal polarity
Inverted polarity
Triggers on negative going sync pulses
Triggers on positive going sync pulses
Figure 2-58 Table 2-34 The Alternative menu (Trigger Mode: Video Page 2/2)
Trigger on all lines
Trigger on an specified line
Select to trigger on odd field or even
field
Select the specified line number for sync
To go to set up menu, see table 2-39
To Next Page
