Rigol DS1000 Series User Manual

RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
VI
General-Purpose Oscilloscopes
RIGOL DS1000-Series Digital Oscilloscopes offer exceptional waveform viewing
and measurements in a compact, lightweight package. The DS1000 series is ideal for
production test, field service, research, design, education and training involving
applications involving analog/digital circuits test and troubleshooting, as well as
education and training.
Each of these oscilloscopes gives you:
 Dual Channel, Bandwidth:
100MHz (DS1102CD, DS1102C, DS1102MD, DS1102M)
60MHz (DS1062CD, DS1062C, DS1062MD, DS1062M)
40MHz (DS1042CD, DS1042C, DS1042MD, DS1042M)
25MHz (DS1022CD, DS1022C, DS1022MD, DS1022M)
 Optional 16 digital channels (DS1000xD), each channel can be turned on or off
independently, or in a 8 bit group
 Mono/Color TFT LCD Displays at 320×234 resolution
 USB storage and printing supports, firmware upgradeable via USB connectivity
 Adjustable waveform intensity, more effective waveform viewing
 One-touch automatic setup for ease of use (AUTO)
 Saves 10 Waveforms, 10 setups, supports CSV and bitmap format
 Newly designed Delayed Scan Function, easy to give attention to both details and
overview of a waveform
 20 Automatic measurements
 Automatic cursor tracking measurements
 Waveform recorder, record and replay dynamic waveforms
 User selectable fast offset calibration
 Built-in FFT function, Frequency Counter
 Digital filters, includes LPF, HPF, BPF, BRF
 Pass/Fail Function, optically isolated Pass/Fail output
 Add, Subtract and Multiply Mathematic Functions
 Advanced trigger types include: Edge, Video, Pulse width, Slope, Alternative,
Pattern and Duration (DS1000xD)
 Adjustable trigger sensitivity
