User’s Guide for DS1000CA Series
2-81
4. Key Test:
Press this soft button to run Keyboard Test program and start the keyboard test
routine. The blocks represent the buttons on the front-panel; the rectangular boxes
with two arrows beside represent the knobs on the front-panel; the square boxes
represent the pressing function for the
knobs. Test all keys and knobs,
and check the responsiveness of the blocks on the screen.
NOTE:
1. The corresponding blocks on the screen will temporary turn into green when
pressing a key.
2. The blocks will reverse its color to red when the corresponding key or knob gets
pressed, and the color will keep reversed during the test.
3. Key backlight lamps will be lit one by one to determine if every backlight LED
works well.
4. Follow the prompting message of "<<Press RUN’ Key Three Times to Exit the
Test>>" to exit the test.
