User’s Guide for DS1000CA Series
NOTE: Moving cursor horizontally is not allowed when other (not tracking cursor)
menu is activated.
(4) To get measurement values:
Position of Cursor 1 (Time cursor centered on the midpoint of screen; Voltage
cursor centered on channel ground level).
Position of Cursor 2 (Time cursor centered on the midpoint of screen; Voltage
cursor centered on channel ground level).
Read the horizontal space between Cursor 1 and 2 (
△X): Time between cursors,
units in seconds.
(1/
△X), units in Hz, kHz, MHz, GHz.
Vertical space between cursor 1 and 2 (
△Y): Voltage between cursors, units in V.
