RIGOL
5-2 Copyright ©1998-2008 RIGOL Technologies, Inc.
User’s Guide for DS1000CA Series
Horizontal
Sample Rate Range 1Sa/s-2GSa/s (Real-Time), 50GSa/s (Equivalent)
Waveform interpolation Sin(x)/x
Record Length 10k samples for single channel, 5k samples for each
channel
Scan speed Range
(Sec/div)
1ns/div-50s/div, DS1302CA
2ns/div-50s/div, DS1102CA, DS1202CA
5ns/div-50s/div, DS1060CA
1-2-5 Sequence
Sample Rate and
Delay Time Accuracy
±50ppm (over any≥1ms time interval)
Delta Time
Measurement Accuracy
(Full Bandwidth)
Single-shot: ±(1 sample interval + 50ppm × reading +
0.6 ns)
>16 averages: ±(1sample interval + 50ppm × reading
+ 0.4 ns)
