Vertical
A/D converter 8-bit resolution, each channel samples simultaneously
Volts/div Range 1mV/div-10V/div at input BNC
Offset Range
±40V(500mV-10V), ±800mV(1mV-200mV)
Analog Bandwidth
60MHz(DS1062CA)
100MHz(DS1102CA)
200MHz(DS1202CA)
300MHz(DS1302CA)
Single-shot
Bandwidth
60MHz(DS1062CA)
100MHz(DS1102CA)
200MHz(DS1202CA)
300MHz(DS1302CA)
Selectable Analog
Bandwidth Limit
(typical)
20MHz
Lower Frequency
Limit (AC -3dB)
5Hz (at input BNC)
Rise Time at BNC,
typical
<1.2ns, <1.7ns, <3.5ns, <5.8ns,
On (300M) (200M) (100M) (60M) respectively
Dynamic range ±5div
DC Gain Accuracy 1mV/div: ±8% (Sample or Average acquisition mode)
2mV/div-5mV/div: ±4% (Sample or Average acquisition
mode)
10mV/div-10V/div: ±3% (Sample or Average acquisition
mode)
DC Measurement
Accuracy, Average
Acquisition Mode
Average of 16 Waveforms with vertical position at zero:
±(DC Gain Accuracy×reading+0.1div+1mV)
Average of 16 Waveforms with vertical position not at zero:
±[DC Gain Accuracy×(reading+ vertical position)+(1% of
vertical position)+0.2div]
Add 2mV for settings from 1mV/div to 200 mV/div
Add 50mV for settings from 200mV/div to 5V/div
Delta Volts
Measurement
Accuracy (Average
Acquisition Mode)
Delta Volts between any two averages of 16 waveforms
acquired under same setup and ambient
conditions: ±(DC Gain Accuracy×reading + 0.05 div)
