RIGOL
Copyright ©1998-2008 RIGOL Technologies, Inc.
User’s Guide for DS1000CA Series
5-5
Measurements
Cursor
Manual Voltage difference between cursors (V)
Time difference between cursors (T)
Reciprocal of T in Hertz (1/T)
Track Voltage value for Y-axis waveform
Time value for X-axis waveform
Auto Cursors are visible for Automatic Measurement
Auto Measure Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot,
Preshoot, Freq, Period, Rise Time, Fall Time, +Width, -Width,
+Duty, -Duty, Delay12
, Delay12
[1] Only one input channel is available when Sample rate is at 2GSa/s.
[2] This is the highest specification, the specific specifications are as follows:
DS1302CA: 50G/s
DS1202CA, DS1102CA: 25G/s
DS1062CA: 10G/s
[3] For DS1202CA and DS1302CA only.
General Specifications
Display
Display Type 5.7 in. (145 mm) diagonal TFT Liquid Crystal
Display
Display Resolution 320 horizontal ×RGB×234 vertical pixels
Display Color 64k color
Display Contrast (typical) 150:1
Backlight Brightness (typical) 300 nit
Probe Compensator Output
Output Voltage (typical) 3 Vp-p into 1 M load
Frequency (typical) 1kHz
Power
Supply Voltage 100 ~ 240 VAC
RMS
, 45-440Hz, CAT II
Power Consumption Less than 50VA
Fuse 2A, T rating, 250 V
