RIGOL
Copyright ©1998-2008 RIGOL Technologies, Inc.
User’s Guide for DS1000CA Series
2-29
z Use the horizontal knob to change the position of the expanded
portion.
z Use the horizontal
knob to adjust the Delayed Scan resolution.
z To change the main time base, turn off the Delayed Scan mode.
z Since both the main and Delayed Scan are displayed; there are half as many
vertical divisions so the vertical scaling is doubled. Notice the changes in the
status bar.
Delayed Scan Shortcut Key:
Delayed Scan function can be activated not only by menu but also by pressing
horizontal
knob.
