Chapter 6 MATH and Measurement RIGOL
DS1000Z-E User Guide 6-17
Sqrt
Calculate the square root of the selected source point by point and display the results.
When the operation is invalid, "NAN" is displayed at the bottom of the screen.
Press MATH  Math  Operator to select "Sqrt":
 Press Operation to enable or disable the "Sqrt" operation function.
 Press Source to select the desired channel (CH1, CH2, or fx (please refer to the
introduction in "Fx Operation")).
 Press Offset and use to adjust the vertical position of the operation results.
 Press Scale and use to adjust the vertical scale of the operation results.
 Press Scale Reset to adjust the vertical scale of the operation results to the
optimal value according to the current configuration.
 Press Options to set the start and end points of the operation results, enable or
disable waveform invert, etc.
― Press Start and use to set the start point of the operation results.
― Press End and use to set the end point of the operation results.
― Press Invert to enable or disable the inverted display function of the
waveform.
― Press Auto Scale to enable or disable the auto scale function. When auto
scale is enabled, the instrument will adjust the vertical scale of the
operation results to the optimal value according to the current
configuration.
― Press fx Operator, fx A and fx B to set the operator and signal sources of
the inner layer operation of Fx operation (please refer to the introduction in
"Fx Operation").
Note: Smooth is grayed out and disabled. Smooth is only available for
differential operation.
 You can also use HORIZONTAL POSITION and HORIZONTAL
SCALE to adjust the horizontal position and scale of the operation results.
Lg (Use 10 as the Base)
Calculate the logarithm of the selected source (use10 as the base) point by point and
display the results. When the operation is invalid, "NAN" is displayed at the bottom of
the screen.
Press MATH  Math  Operator to select "Lg":
 Press Operation to enable or disable the "Lg" operation function.
 Press Source to select the desired channel (CH1, CH2, or fx (please refer to the
introduction in "Fx Operation")).
