RIGOL Chapter 6 MATH and Measurement
6-24 DS1000Z-E User Guide
One-key Measurement of 37 Parameters
Press MENU at the left of the screen to turn on the measurement menu of the 37
parameters and then press the corresponding menu softkey to quickly realize
"One-key" measurement. The measurement results can be displayed at the bottom
of the screen in various font sizes (press Measure Font Size to select "Normal",
"Large" or "Extra Large").
The time and voltage parameters icons in the measurement items and the
measurement results on the screen are always marked in the same color with the
channel (Measure Source) currently used.
The parameter icons and the measurement results of delay and phase are always
marked in white. The colors of the numbers (1 and 2) in the icons and results are
related to the measurement source currently selected. When the measurement
source is an analog channel, the color of 1 or 2 is the same with that of the channel
selected.
Note: If the measurement result is displayed as "*****", it means that there is no
signal input in the current source or the measurement result is not within the valid
range (too large or too small).
