Chapter 6 MATH and Measurement RIGOL
DS1000Z-E User Guide 6-39
BY: the Y value at cursor B. The Y value takes the channel GND as reference and
use the same unit as the current source.
BX-AX: the horizontal difference between cursors A and B.
BY-AY: the vertical difference between cursors A and B.
1/|dX|: the reciprocal of the horizontal difference between cursors A and B.
If needed, please refer to the following steps to modify the track cursor
measurement parameters.
1. Select Measurement Source
Press CursorA to select the waveform of analog channels (CH1 and CH2) or
math operation results (MATH) as the measurement source of cursor A (only
channels enabled are available). You can also select "None", namely do not use
cursor A.
Press CursorB to select the waveform of analog channels (CH1 and CH2) or
math operation results (MATH) as the measurement source of cursor B (only
channels enabled are available). You can also select "None", namely do not use
cursor B.
2. Adjust Cursor Position
Adjust cursor A: press CursorA and use to adjust the position of cursor
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursor A and B at the same time: press CursorAB and use to
adjust the position of cursor A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable range is limited within the screen.
Note:
― Under the current menu, you can rotate to switch the current
cursor.
― In track mode, the cursor will track the marked point (namely jumps up
and down with the transient change of the waveform). Thus, the Y
value might change even though you do not adjust the cursor.
