Rigol DS1000Z-E Series

Chapter 12 Store and Recall RIGOL
DS1000Z-E User Guide 12-17
Bus Width
8
Bit X
0
Channel
CH1
RS232
TX
CH1
Polarity
Baud
9600
RX
OFF
Order
LSB
Data Bits
8
Stop Bit
1
Parity
None
I2C
CLK
CH1
DATA
CH2
Address Mode
Normal
SPI
CLK
CH1
MISO
OFF
MOSI
CH2
Mode
Timeout
Timeout
1.00 us
Edge
Rising Edge
Polarity
Width
8
Order
MSB
Decoding Configuration
Label
ON
Line
ON
Format
ON
Endian
OFF
Width
OFF
Data Source
Traces
Reference Waveform Setting (REF)
Channel Setting
Ref1
Current Channel
Ref1
Source
CH1
Offset
0.00 nV
Scale
100 mV
Color
Light Gray
