RIGOL Chapter 5 To Trigger the Oscilloscope
5-16 DS1000Z-E User Guide
 or : set the pattern to the rising or falling edge of the channel selected.
Note:
Only one edge (rising or falling edge) can be specified in the pattern. If one edge
item is currently defined and then another edge item is defined in another channel in
the pattern, the former edge item defined will be replaced by X.
All Bits:
Press AllBits to set the patterns of all trigger sources to the pattern settings selected
currently.
Trigger Mode:
Press Sweep to open the trigger mode list and select auto, normal or single. For the
details, please refer to "Trigger Mode". The corresponding status light of the
current trigger mode turns on.
Trigger Setting:
Press Setting to set the trigger parameters (trigger holdoff and noise rejection)
under this trigger type.
Trigger Level:
For the analog channels, the trigger level of each channel needs to be set
independently. For example, set the trigger level of CH1. Press Source to select CH1,
and then use TRIGGER LEVEL to modify the level. For the details, please refer
to the introduction of "Trigger Level".
