Rigol DS1000Z Series Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-87
:TRIGger:EDGe:LEVel
Syntax :TRIGger:EDGe:LEVel <level>
:TRIGger:EDGe:LEVel?
Description Set or query the trigger level in edge trigger. The unit is the same as the current
amplitude unit.
Parameter
Name
Type
Range
Default
<level> Real (± 5 × VerticalScale from the screen center) - OFFSet 0
Explanation For VerticalScale, refer to the :CHANnel<n>:SCALe command. For OFFSet, refer to
the :CHANnel<n>:OFFSet command.
Return
Format
The query returns the trigger level in scientific notation.
Example
:TRIGger:EDGe:LEVel 0.16
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
