:MATH Commands
The :MATH commands are used to set the operations between the waveforms of multiple channels.
Note:
 The operations can be divided into two types.
Analog Operations: A+B, A-B, A×B, A/B, FFT, intg, diff, sqrt, lg, ln, exp and abs
Logic Operation: A&&B, A||B, A^B and !A
 For the logic operation, the waveform data to be operated is compared with the preset threshold and is
converted to 0 or 1. Thus, the result will also be 0 or 1.
 For the analog operation or logic operation which needs only one source, only the
:MATH:SOURce1
command will be used.
Command List:
 :MATH:DISPlay
 :MATH:OPERator
 :MATH:SOURce1
 :MATH:SOURce2
 :MATH:SCALe
 :MATH:OFFSet
 :MATH:INVert
 :MATH:RESet
 :MATH:FFT:WINDow
 :MATH:FFT:SPLit
 :MATH:FFT:UNIT
 :MATH:FFT:HSCale
 :MATH:FFT:HCENter
 :MATH:OPTion:STARt
 :MATH:OPTion:END
 :MATH:OPTion:INVert
 :MATH:OPTion:SENSitivity
 :MATH:OPTion:DIStance
 :MATH:OPTion:ASCale
 :MATH:OPTion:THReshold1
 :MATH:OPTion:THReshold2
