:TRIGger:VIDeo
Command List:
 :TRIGger:VIDeo:SOURce
 :TRIGger:VIDeo:POLarity
 :TRIGger:VIDeo:MODE
 :TRIGger:VIDeo:LINE
 :TRIGger:VIDeo:STANdard
 :TRIGger:VIDeo:LEVel
:TRIGger:VIDeo:SOURce
Syntax :TRIGger:VIDeo:SOURce <source>
:TRIGger:VIDeo:SOURce?
Description
Select or query the trigger source in video trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:VIDeo:SOURce CHANnel2
:TRIGger:VIDeo:POLarity
Syntax :TRIGger:VIDeo:POLarity <polarity>
:TRIGger:VIDeo:POLarity?
Description
Select or query the video polarity in video trigger.
Parameter
Name
Type
Range
Default
<polarity> Discrete {POSitive|NEGative} POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:VIDeo:POLarity POSitive
