Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-124 DS1000Z Programming Guide
:TRIGger:RS232:LEVel
Syntax :TRIGger:RS232:LEVel <level>
:TRIGger:RS232:LEVel?
Description Set or query the trigger level in RS232 trigger. The unit is the same as the current
amplitude unit.
Parameter
Name
Type
Range
Default
<level> Real (± 5 × VerticalScale from the screen center) - OFFSet 0
Explanation For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return Format
The query returns the trigger level in scientific notation.
Example :TRIGger:RS232:LEVel 0.16 /*Set the trigger level to 160mV*/
:TRIGger:RS232:LEVel? /*The query returns 1.600000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
