RIGOL Chapter 2 Command System
2-18 DS1000Z Programming Guide
:CURSor:MANual:AX
Syntax :CURSor:MANual:AX <x>
:CURSor:MANual:AX?
Description
Set or query the horizontal position of cursor A in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<x> Integer 5 to 594 100
Explanation The horizontal and vertical positions of the cursor are defined by the pixel coordinate of
the screen. The pixel coordinate of the screen ranges from (0,0) to (600,400). Wherein,
(0,0) is located at the left top corner of the screen and (600,400) is located at the right
bottom corner of the screen. The horizontal pixel range is from 0 to 600 and the vertical
pixel range is from 0 to 400.
Return
Format
The query returns an integer between 5 and 594.
Example
:CURSor:MANual:AX 200 /*Set the horizontal position of cursor A to 200*/
:CURSor:MANual:BX
Syntax :CURSor:MANual:BX <x>
:CURSor:MANual:BX?
Description
Set or query the horizontal position of cursor B in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<x>
Integer
5 to 594
500
Explanation The horizontal and vertical positions of the cursor are defined by the pixel coordinate of
the screen. The pixel coordinate of the screen ranges from (0,0) to (600,400). Wherein,
(0,0) is located at the left top corner of the screen and (600,400) is located at the right
bottom corner of the screen. The horizontal pixel range is from 0 to 600 and the vertical
pixel range is from 0 to 400.
Return
Format
The query returns an integer between 5 and 594.
Example
:CURSor:MANual:BX 200 /*Set the horizontal position of cursor B to 200*/
:CURSor:MANual:AY
Syntax :CURSor:MANual:AY <y>
:CURSor:MANual:AY?
Description
Set or query the vertical position of cursor A in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<y>
Integer
5 to 394
100
Explanation The horizontal and vertical positions of the cursor are defined by the pixel coordinate of
the screen. The pixel coordinate of the screen ranges from (0,0) to (600,400). Wherein,
(0,0) is located at the left top corner of the screen and (600,400) is located at the right
bottom corner of the screen. The horizontal pixel range is from 0 to 600 and the vertical
pixel range is from 0 to 400.
Return
Format
The query returns an integer between 5 and 394.
Example :CURSor:MANual:AY 200 /*Set the vertical position of cursor A to 200*/
