Chapter 6 MATH and Measurement RIGOL
MSO1000Z/DS1000Z User’s Guide 6-7
waveform corresponding to the horizontal center of the screen.
4. Horizontal Scale
Press Hz/Div and use to adjust the horizontal scale of the frequency
domain waveform.
5. Vertical Position
Press Offset and use to adjust the vertical position of the operation results.
6. Vertical Scale
Press Scale and use to adjust the vertical scale of the operation results.
7. Select Window Function
Spectral leakage can be considerably decreased when a window function is used.
MSO1000Z/DS1000Z provides six kinds of FFT window functions (as shown in
the table on the next page) which have different characteristics and are
applicable to measure different waveforms. You need to select the window
function according to the waveform to be measured and its characteristics. Press
Window to select the desired window function and the default is "Rectangle".
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
