Chapter 13 Signal Source RIGOL
MSO1000Z/DS1000Z User’s Guide 13-1
Chapter 13 Signal Source
MSO1000Z/DS1000Z combines signal generator and oscilloscope in one instrument
by providing a built-in dual-channel, 25MHz signal generator, thus providing
convenience for engineers who need to use the signal generator and oscilloscope at
the same time. This chapter introduces how to use the built-in signal generator. As
the functions and setting methods of source 1 and source 2 are the same, this
chapter takes source 1 for illustration.
Press Source to enter the signal generator control menu.
Press Output to enable or disable the signal output. When it is enabled, the
[Source 1] connector at the rear panel outputs a signal according to the
current setting.
Press Src1Conf to set the signal type and the signal parameters.
Pressing AlignPhase can align the phases of the signals output from source 1
and source 2.
Press StatusDisp to view the parameter settings of source 1 and source 2, such
as the frequency, amplitude, offset, phase, modulation type and modulation
frequency, etc.
Press RecoveryCalls to set the output signal type and parameters to be
recalled when the oscilloscope is powered on again after power-off. You can
select "Last" or "Default".
Pressing Factory can restore the default settings of the signal source
separately.
Note: The function of Source Output is the same with that of Source
Src1Conf Output.
The contents of this chapter:
To Output Basic Waveform
To Output Built-in Waveform
To Output Arbitrary Waveform
Modulation
