RIGOL Chapter 11 Waveform Record
11-2 MSO1000Z/DS1000Z User’s Guide
Common Settings
Press Utility Record Record to turn on or off the waveform record function.
1. Record Waveform
Before recording the waveform, you can refer to the introduction in "
Record
Option" to set the waveform recording parameters. Press Record to start
recording the waveform. During the recording, the current recording information
as shown in the figure below is displayed at the upper right corner of the screen.
"●" in the menu changes to "■" automatically. At this point, press Record
again to stop recording.
Under the waveform recording menu, pressing RUN/STOP can also start and
stop the recording.
2. Play
Press Play to start playing the waveform recorded. For more details, please
refer to the introduction in "
Playback Option".
3. Stop
During the playback, you can press Stop to stop the playback.
4. Current Frame
Press Current and use to set the current frame. The default is the
maximum number of frames recorded currently. During the setting, the screen
will display the corresponding waveform of the current frame synchronously,
namely manual playback.
5. Step Direction
Press Step Dir to select the single frame playback direction of the recorded
waveform.
: press SINGLE to play the single frame forward (namely the
single frame playback sequence is the same as the waveform record
sequence) and the number of the frame is incremental.
: press SINGLE to play the single frame backward (namely the
single frame playback sequence is opposite to the waveform record
sequence) and the number of the frame is decremental.
6. The Last/First Frame
You can view the last or first frame of waveform. Pressing
can jump to
the last frame of the recorded waveform; pressing
can jump to the first
frame of the recorded waveform.
