Chapter 15 Accessibility Setting RIGOL
MSO1000Z/DS1000Z User’s Guide 15-5
press DNS and use to input the desired address. Generally, users do not need to
set the DNS, therefore this parameter setting can be ignored.
Tips
 When the three IP configuration types are all turned on, the priority of the
parameter configuration from high to low is "DHCP", "Auto IP" and "Static IP".
 The three IP configuration types cannot be all turned off at the same time.
Apply the Network Parameter Setting
Press Apply to validate the current network parameter setting.
Initialize the Network Parameters
Press Initialize to return the network parameters to the default state.
MAC Address
For each oscilloscope, the MAC address is unique. When attributing IP address for
the oscilloscope, the MAC address is usually used to identify the instrument.
VISA Address
Display the VISA address currently used by the oscilloscope.
USB Device
Press Utility  IO Setting  USB Device to select the device type ("Computer"
or "PicBridge") connected to the USB device interface and the default is "Computer".
When "Computer" is selected, the oscilloscope can communicate with the PC. When
"PictBridge" is selected, you can print the content displayed on the screen via a
PicBridge printer.
