Rigol DS1054Z User Manual

RIGOL Chapter 14 Store and Recall
14-12 MSO1000Z/DS1000Z User’s Guide
Factory
Press Storage Default to return the oscilloscope to its factory state (refer to the
table below).
Table 14-1 Factory
Parameter
Factory
Horizontal Setting (HORIZONTAL)
Vertical Setting (VERTICAL)
Acquisition Setting (Acquire)
Trigger Setting (TRIGGER)
Display Setting (Display)
Signal Source (Source)
Cursor Setting (Cursor)
Storage Setting (Storage)
Utility Function Setting (Utility)
Math Operation Setting (MATHMath)
LA
Protocol Decoding (MATH Decode 1/Decode 2)
Reference Waveform Setting (REF)
Horizontal Setting (HORIZONTAL)
Horizontal Time Base
1 μs
Horizontal Offset
0 s
Delayed Sweep OFF
Time Base Type YT
Vertical Setting (VERTICAL)
Vertical Scale
1 V
Vertical Offset
0.00 V
CH1 Switch ON
CH2 Switch OFF
CH3 Switch OFF
CH4 Switch
OFF
Channel Coupling
DC
Bandwidth Limit
OFF
Probe Ratio 10X
Invert OFF
Amplitude Scale Coarse
Channel Unit
[V]
Display Label
OFF
Template Label CH1
Delay Calibration 0.00 s
