Rigol DS1054Z User Manual

Chapter 6 MATH and Measurement RIGOL
MSO1000Z/DS1000Z User’s Guide 6-41
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursor A and B at the same time: press CursorAB and use to
adjust the position of cursor A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable range is limited within the screen.
Note:
― Under the current menu, you can rotate
to switch the current
cursor.
― In track mode, the cursor will track the marked point (namely jumps up
and down with the transient change of the waveform). Thus, the Y
value might change even though you do not adjust the cursor.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
