Chapter 14 Store and Recall RIGOL
MSO1000Z/DS1000Z User’s Guide 14-15
Scale 1.00 V
A×B
Operation
OFF
Source A
CH1
Source B
CH1
Offset 0.00 U
Scale 2.00 U
A/B
Operation
OFF
Source A
CH1
Source B CH1
Offset 0.00 U
Scale 50.0 mU
FFT
Operation
OFF
Source
CH1
Center Frequency 5.00 MHz
Horizontal Scale 5.00 MHz
Offset 0.00 dBV
Scale
10.0 dBV
Window Function
Rectangle
Mode
Trace
View Half
Unit dB/dBm
A&&B
Operation
OFF
Source A
D0
Source B
D1
Offset 0.00 V
Scale 1.00 V
Threshold A 0.00 V
Threshold B
0.00 V
A||B
Operation OFF
Source A D0
Source B D1
Offset
0.00 V
Scale
1.00 V
Threshold A
0.00 V
Threshold B 0.00 V
A^B
Operation OFF
Source A
D0
Source B
D1
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
