Rigol DS1054Z User Manual

RIGOL Chapter 16 Remote Control
16-4 MSO1000Z/DS1000Z User’s Guide
3. Search for device resource
Start up Ultra Sigma and the software will automatically search for the
instrument resources currently connected to the PC via the USB interface. You
can also click
to search for the resources.
4. View the device resource
The resources found will appear under the "RIGOL Online Resource" directory
and the model number and USB interface information of the instrument will also
be displayed.
For example, MSO1104Z (USB0::0x1AB1::0x04CE::DS1ZD170800001::INSTR).
7
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
