Rigol DS1054Z User Manual

RIGOL Chapter 18 Specifications
18-2 MSO1000Z/DS1000Z User’s Guide
Horizontal
Timebase Scale
5 ns/div to 50 s/div
Max Record
Length
24 Mpts (optional)
Timebase
Accuracy
[1]
≤±25 ppm
Clock Drift ≤±5 ppm/year
Max Delay
Range
Negative delay: 1/2 (memeory depth/sample rate)
Positive delay: 1 s to 500 s
Timebase Mode YT, XY, Roll
Number of X-Y 1
Waveform
Capture Rate
[2]
30,000 wfms/s (dots display)
Zero Offset ±0.5 div×minimum time base scale
Vertical
Bandwidth
(-3 dB)
MSO1104Z/1104Z-S and DS1104Z Plus/1104Z-S Plus: DC to 100
MHz
MSO1074Z/1074Z-S and DS1074Z Plus/1074Z-S Plus: DC to 70
MHz
DS1054Z: DC to 50 MHz
Single-shot
Bandwidth
MSO1104Z/1104Z-S and DS1104Z Plus/1104Z-S Plus: DC to 100
MHz
MSO1074Z/1074Z-S and DS1074Z Plus/1074Z-S Plus: DC to 70
MHz
DS1054Z: DC to 50 MHz
Vertical
Resolution
Analog channel: 8 bit
Digital channel: 1 bit
Vertical Scale
(Probe ratio is
1X)
1 mV/div to 10 V/div
Offset Range
(Probe ratio is
1X)
1 mV/div to 499 mV/div: ±2 V
500 mV/div to 10 V/div: ±100 V
Bandwidth
Limit
[1]
20 MHz
Low Frequency
Response
(AC Coupling,
-3dB)
≤5 Hz (on BNC)
Calculated Rise
Time
[1]
MSO1104Z/1104Z-S and DS1104Z Plus/1104Z-S Plus: 3.5 ns
MSO1074Z/1074Z-S and DS1074Z Plus/1074Z-S Plus: 5 ns
DS1054Z: 7 ns
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
