Rigol DS1054Z User Manual

RIGOL Chapter 18 Specifications
18-6 MSO1000Z/DS1000Z User’s Guide
Number of
Measurements
Display 5 measurements at the same time
Measurement
Range
Screen or cursor
Measurement
Statistic
Average, Max, Min, Standard Deviation, Number of
Measurements
Frequency
Counter
Hardware 6 bit frequency counter
(channels are selectable)
Math Operation
Waveform
Operation
A+B, A-B, A×B, A/B, FFT, A&&B, A||B, A^B, !A, Intg, Diff, Sqrt,
Lg, Ln, Exp, Abs, Filter
FFT Window
Function
Rectangle, Hanning, Blackman, Hamming, Flat Top, Triangle
FFT Mode
Trace, Memory
FFT Display
Half, Full
FFT Vertical Scale
dB/dBm, Vrms
Filter Low Pass Filter, High Pass Filter, Band Pass Filter, Band Stop
Filter
Number of Buses
for Decoding
2
Decoding Type Parallel (standard), RS232/UART (optional), I2C (optional), SPI
(optional)
Display
Screen Type 7.0 inch (203 mm) TFT LCD display
Display
Resolution
800 Horizontal×RGB×480 Vertical Pixel
Display Color
16 Million Color (24 bit true color)
Persistence Time
Min, 100 ms, 200 ms, 500 ms, 1 s, 5 s, 10 s, Infinite
Display Type
Dots, Vectors
I/O
Standard Ports USB Host, USB Device, LAN, Aux Output (TrigOut/PassFail)
Signal Source (Applicable to Digital Oscilloscopes with Source
Channels)
Channels
2
Sample Rate
200 MSa/s
Vertical
Resolution
14 bits
Max. Frequency
25 MHz
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
