RIGOL Chapter 3 Performance Test
Service Guide for DS1000E, DS1000D Series
3-12
Impedance Test
Specifications:
Input Impedance
1 MΩ ±2% (0.98 MΩ to 1.02 MΩ)
Test Devices: Fluke 9500B or Digital Multimeter and BNC (male) to Dual-banana
Plug Cable. In this manual, the test device is Fluke 9500B.
Test Procedures:
1. Impedance test of CH1 and CH2
1) Connect the active head of Fluke 9500B to CH1 of the oscilloscope.
2) Configure the oscilloscope:
a) Press CH1 in the vertical control area (VERTICAL) at the front panel to
enable CH1.
b) Rotate VERTICAL SCALE to set the vertical scale of CH1 to 100
mV/div.
3) Enable the Fluke 9500B and select the resistance measurement function,
read and record the resistance measurement value.
4) Rotate VERTICAL
SCALE to adjust the vertical scale of CH1 to 500
mV/div; then, read and record the resistance measurement value.
5) Turn CH1 off. Repeat the above test steps to test CH2 and record the test
results.
2. Impedance test of [EXT TRIG] channel
1) Disconnect the connections of the two input channels.
2) Connect the active head of Fluke 9500B to the external trigger channel [EXT
TRIG].
3) Enable the Fluke 9500B and select the resistance measurement function,
read and record the resistance measurement value.
Test Record Form:
Channel
Vertical Scale
Test Result
Limit
Pass/Fail
CH1
100 mV/div
≥ 0.98 MΩ and ≤ 1.02
MΩ
500 mV/div
CH2
100 mV/div
500 mV/div
EXT TRIG
--

Rigol DS1102E Specifications

General

Bandwidth	100 MHz
Sample Rate	1 GSa/s
Channels	2
Memory Depth	1 Mpts
Vertical Sensitivity	2 mV/div to 10 V/div
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Vertical Resolution	8 bits
Input Coupling	DC, AC, GND
Power Supply	100-240 V AC, 45-440 Hz
Display	5.7 inch TFT LCD
Display Resolution	320 x 234
Interfaces	USB Host, USB Device
Input Impedance	1 MΩ ±2%, 15 pF ±3 pF
Dimensions	303 mm x 154 mm x 133 mm
