Rigol DS1102E Service Guide

RIGOL Chapter 3 Performance Test
Service Guide for DS1000E, DS1000D Series
3-20
Time Base Accuracy Test
Specification:
Time Base Accuracy
≤ ±
50 ppm
Test Devices: Fluke 9500B or signal generator and BNC (m)-BNC (m) cable.
Test procedures:
1) Connect the active head of Fluke 9500B to CH1 of the oscilloscope.
2) Output a sine waveform with 10 MHz frequency and 1 Vpp amplitude from
Fluke 9500B.
3) Configure the oscilloscope:
a) Press CH1 in the vertical control area (VERTICAL) at the front panel to
enable CH1.
b) Rotate VERTICAL SCALE to set the vertical scale to 200 mV/div.
c) Rotate VERTICAL POSITION to set the vertical position to 0.
d) Rotate HORIZONTAL SCALE to set the horizontal time base to 20
ns.
e) Rotate HORIZONTAL POSITION to set the horizontal position to
1 ms.
4) Observe the display of the oscilloscope and measure the offset (ΔT) of the
midpoint of the signal relative to the center of the screen.
5) Calculate the time base accuracy, namely the ratio of ΔT to the horizontal
position of the oscilloscope. For example, if the offset of this test is 8 ns, the
time base accuracy is 10 ns/1 ms=10 ppm.
Test Record Form:
Channel Test Result ΔT
Calculation
Result
Limit Pass/Fail
CH1 ±50 ppm

Rigol DS1102E Specifications

General

Bandwidth	100 MHz
Sample Rate	1 GSa/s
Channels	2
Memory Depth	1 Mpts
Vertical Sensitivity	2 mV/div to 10 V/div
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Vertical Resolution	8 bits
Input Coupling	DC, AC, GND
Power Supply	100-240 V AC, 45-440 Hz
Display	5.7 inch TFT LCD
Display Resolution	320 x 234
Interfaces	USB Host, USB Device
Input Impedance	1 MΩ ±2%, 15 pF ±3 pF
Dimensions	303 mm x 154 mm x 133 mm
