Rigol DS1102E Service Guide

RIGOL Chapter 3 Performance Test
Service Guide for DS1000E, DS1000D Series
3-14
Test Record Form:
Channel
Vertical
Scale
Test Result
Limit Pass/Fail
Vavg1 Vavg2
Calculation
Result
[1]
CH1
2 mV/div
≤4%
5 mV/div
10 mV/div
≤3%
20 mV/div
50 mV/div
100
mV/div
200
mV/div
500
mV/div
1 V/div
2 V/div
5 V/div
10 V/div
CH2
2 mV/div
≤4%
5 mV/div
10 mV/div
≤3%
20 mV/div
50 mV/div
100
mV/div
200
mV/div
500
mV/div
1 V/div
2 V/div
5 V/div
10 V/div
Note
[1]
: the calculation formula is |(Vavg1–Vavg2)–(V
out1
-V
out2
)|/Full Scale×100%; wherein, V
out1
and V
out2
are 3 and -3 times of the current vertical scale respectively.

Rigol DS1102E Specifications

General

Bandwidth	100 MHz
Sample Rate	1 GSa/s
Channels	2
Memory Depth	1 Mpts
Vertical Sensitivity	2 mV/div to 10 V/div
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Vertical Resolution	8 bits
Input Coupling	DC, AC, GND
Power Supply	100-240 V AC, 45-440 Hz
Display	5.7 inch TFT LCD
Display Resolution	320 x 234
Interfaces	USB Host, USB Device
Input Impedance	1 MΩ ±2%, 15 pF ±3 pF
Dimensions	303 mm x 154 mm x 133 mm
