Rigol DS1104Z-S Plus Programming Guide

RIGOL Chapter 2 Command System
2-102 MSO1000Z/DS1000Z Programming Guide
:MATH:OPTion:END
Syntax
:MATH:OPTion:END <end>
:MATH:OPTion:END?
Description
Set or query the end point of the waveform math operation.
Parameter
Name
Type
Range
Default
<end>
Discrete
(Start point currently set+1) to 1199
1199
Explanation
 This command is invalid for the FFT operation. Sending this command will modify the
end points of all the operations (except FFT).
 The source selected is equally divided into 1200 parts horizontally, in which the
leftmost is 0 and the rightmost is 1199.
Return
Format
The query returns an integer.
Example
:MATH:OPTion:END 200 /*Set the waveform end point to 200*/
:MATH:OPTion:END? /*The query returns 200*/
Related
Command
:MATH:OPTion:STARt
:MATH:OPTion:INVert
Syntax
:MATH:OPTion:INVert <bool>
:MATH:OPTion:INVert?
Description
Enable or disable the inverted display mode of the operation result, or query the inverted
display mode status of the operation result.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
 This command is invalid for the FFT operation. Sending this command will modify
the inverted display mode status of all the operations (except FFT).
 This command has the same function as the :MATH:INVert command.
Return
Format
The query returns 1 or 0.
Example
:MATH:OPTion:INVert ON /*Enable the inverted display mode*/
:MATH:OPTion:INVert? /*The query returns 1*/
