:CURSor:TRACk
Command List:
 :CURSor:TRACk:SOURce1
 :CURSor:TRACk:SOURce2
 :CURSor:TRACk:AX
 :CURSor:TRACk:BX
 :CURSor:TRACk:AY?
 :CURSor:TRACk:BY?
 :CURSor:TRACk:AXValue?
 :CURSor:TRACk:AYValue?
 :CURSor:TRACk:BXValue?
 :CURSor:TRACk:BYValue?
 :CURSor:TRACk:XDELta?
 :CURSor:TRACk:YDELta?
 :CURSor:TRACk:IXDELTA?
:CURSor:TRACk:SOURce1
Syntax
:CURSor:TRACk:SOURce1 <source>
:CURSor:TRACk:SOURce1?
Description
Set or query the channel source of cursor A in the track cursor measurement mode.
Parameter
Name
Type
Range
Default
<source>
Discrete
{OFF|CHANnel1|CHANnel2|CHANnel3|
CHANnel4|MATH}
CHANnel1
Explanation
Only the channels enabled can be selected as the channel source.
Return
Format
The query returns OFF, CHAN1, CHAN2, CHAN3, CHAN4, or MATH.
Example
:CURSor:TRACk:SOURce1 CHANnel2 /*Set the channel source to CH2*/
:CURSor:TRACk:SOURce1? /*The query returns CHAN2*/
