Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-115
5. Other Parameters
Divide the difference of the upper value and lower value on the rising edge by the
corresponding time.
Divide the difference of the lower value and upper value on the falling edge by the
corresponding time.
The area of the whole waveform within the screen and the unit is voltage-second. The
area meadured above the zero reference (namely the vertical offset) is positive and
the area measured below the zero reference is negative. The area measured is the
algebraic sum of the area of the whole waveform within the screen.
The area of the first period of the waveform on the screen and the unit is
voltage-second. The area above the zero reference (namely the vertical offset) is
positive and the area below the zero reference is negative. The area measured is the
algeraic sum of the area of the waveform within the whole period.
Command List:
:MEASure:SOURce
:MEASure:COUNter:SOURce
:MEASure:COUNter:VALue?
:MEASure:CLEar
:MEASure:RECover
:MEASure:ADISplay
:MEASure:AMSource
:MEASure:SETup:MAX
:MEASure:SETup:MID
:MEASure:SETup:MIN
:MEASure:SETup:PSA
:MEASure:SETup:PSB
:MEASure:SETup:DSA
:MEASure:SETup:DSB
:MEASure:STATistic:DISPlay
:MEASure:STATistic:MODE
:MEASure:STATistic:RESet
:MEASure:STATistic:ITEM
:MEASure:ITEM
