RIGOL Chapter 6 Specifications
6-8 DSG800 User's Guide
Input and Output
Front Panel Connectors
RF output
Impedance
50 Ω (nom.)
Connector
N female
Internal modulation
generator (LF) output
Impedance
50 Ω (nom.)
Connector
BNC female
Rear Panel Connectors
External trigger input
Impedance
1 (nom.)
Connector
BNC female
Trigger voltage
3.3 V TTL level
Signal valid output
Connector
BNC female
Output voltage
0 V/3.3 V (nom.)
Pulse input or output
Impedance
50 Ω (nom.)
Input/output voltage
0 V/3.3 V (nom.)
External modulation signal
input
Impedance
100 kΩ/600 Ω/50 Ω (nom.)
Coupling
AC/DC
Sensitivity
1 V peak-peak for indicated
modulation depth or deviation
(nom.)
Connector
BNC female
10MHz input (external
frequency reference input)
Impedance
50 Ω (nom.)
Connector
BNC female
10MHz output (external
frequency reference
output)
Impedance
50 Ω (nom.)
Connector BNC female
Rear Panel Communication Interfaces
USB host
Connector
A plug
Protocol
Version 2.0
USB device
Connector
B plug
Protocol
Version 2.0
LAN
LXI Core 2011
Device
10/100Base, RJ-45
