RIGOL Chapter 2 Front Panel Operations
2-24 DSG800 User's Guide
To Select the Pulse Mode
Press Source to select "Int" modulation source; press Mode to select "Single" or
"Train (option DSG800-PUG)".
 Single: only a single pulse signal is generated for a pulse period. This is the
default pulse mode.
 Train: multiple pulse signals are generated for a pulse period. At this point,
Period and Width are grayed out and disabled. You can press Train List to
load or view the desired pulse train.
Note: When "Ext" modulation source is selected, this menu is grayed out and
disabled. To use the "Train" pulse mode, you need to install the option DSG800-PUG.
For the specific installation methods, please refer to "License".
To Set the Pulse Period
The pulse period is the time interval between two neighboring pulses in
periodically-repetitive pulse train.
Press Source to select "Int" modulation source; press Period to set the period of
the "Single" pulse modulating signal.
 Use the numeric keyboard to input the desired value and select the desired unit
from the pop-up unit menu.
 You can press Backspace to delete the number at the left of the cursor.
 You can also use the knob to modify this parameter.
 The range of the pulse period is from 40 ns to 170 s.
 The pulse period determines the repeating frequency of the internal pulse
modulating signal.
Note: When "Ext" modulation source or "Train" pulse mode is selected, this menu is
grayed out and disabled.
